Asphalt Distributor

Asphalt Distributor
Asphalt Distributor Asphalt Distributor Asphalt Distributor Asphalt Distributor

Feiteng offers two types of asphalt distributor to meet actual needs of your project, RLS series and LS series.

RLS series asphalt distributors are mainly designed for spraying emulsified asphalt and modified emulsified asphalt, while our LS series asphalt distributors are typically used for distributing base bitumen and modified asphalt.

Specifications of RLS series asphalt distributor
Model RLS-2 RLS-3 RLS-5
Tank capacity (L) 2000 4000 5000
Spray bar span (m) 4 4 4
Spray rate (L/m2) 0.3～3 0.3～3 0.3～3
Pump capacity (L/min) 400 400 400
No. of spray nozzles 24 24 24
Dimensions (m) (L×W×H) 3×1.6×1.4 3.8×1.9×1.5 4×2×1.7
Specifications of LS series asphalt distributor
Model LS-2 LS-3 LS-5
Tank capacity (L) 2000 4000 5000
Spray bar span (m) 4 4 4
Spray rate (L/m2) 0.3～3 0.3～3 0.3～3
Pump capacity (L/min) 400 400 400
No. of spray nozzles 24 24 24
Heating capacity (kcal) 200.000 200.000 200.000
Dimensions (m) (L×W×H) 3×1.6×1.4 3.8×1.9×1.5 4×2×1.7
Features
  • Spraying rate is adjustable during operation;
  • Spray bar has multiple spray nozzles, each of them can be individually controlled to adapt various spraying span needs. Hand spray lance is equipped to complete road coating and patching works;
  • Strong spray function can be activated when driving speed limited in a range of 0-5km/h, it turns out rated spray accuracy when truck just starts up;
  • Spray nozzles are self-rinsed after end of spraying;
  • This asphalt distributor saves more fuel in comparison with similar products, benefiting from reasonable structure and precise control;
  • In addition to spray asphalt, it can be used as water spraying unit, with an even spray efficiency;
